Saw dust

Collect saw dust during the cutting, edging, surface treatment processes which greatly improvement the environment and prevent injuries from splatter.

Target equipment:

Sawing & drilling: Saw dust from the sawing and cutting process are medium and small size
Milling machine: Wood chips and milling wood dust from sculpturing process are usually large particles
Sander: Sanding process generates large bulk of fine and dry dust

Dust feature:

Wood saw and dust are dry and in large volumes. Particle size varies and contains wood tar with phenols and alkanes which post health threats

Saw dust are explosive and need to be collected with care





PFC-B bag house

Easy cleaning

Select suitable filter bag accoridng to different saw dust features. 208 terylene flannelette or fiber glass combination mat are frequent choices.

Temperature tolerance 482℉

*Pre drop out box option

PFC-C cyclone collector

Cyclone collector to drop larger chips and shavings, and protects the filters behind

*Slide gate/ rotary air lock




  • Hood design

    Source capture hood design is very important in saw dust collection.



  • Explosion proof system

    AS relatively weak section in the collector structure,when pressure withing the bag house reaches preset limit, explosion proove vent will be smashed and release the explosion, guilding the flame to safe area.

    The blast gate can bring down the explosion damage to the collector to minumn 。
